Features:

  1. The optical lenses are made of glass imported from Germany.
  2. All the lenses are multi-coated, mildew proof and anti-reflection.
  3. The adaptor for Applanation Tonometer is universal.

Specifications:

  1. Microscope Type: Converging Stereoscope
  2. Magnification: Two-step magnifications
  3. Eye Piece: 10X, 16X
  4. Total Magnification and Field of View (MM): 10x (Φ18), 16x (Φ14.5), 16x (Φ11.25), 25x (Φ9)
  5. Range of Pupil Distance: 55MM – 82MM (10X), 51MM – 78MM (16X)
  6. Adjustment of Diopter:±8D (10X),±10 (16X)
  7. Slit Width: 0MM – 9MM adjustable
  8. Slit Height: 1MM – 8MM adjustable
  9. Slit Angle: 0° – 180°
  10. Slit Inclination: 5°, 10°, 15°, 20°, 4 ranges chosen
  11. Light Spot Diameter: Φ9, Φ8, Φ5, Φ3, Φ2,  Φ1, Φ0.2
  12. Filter: Heat absorption, grey, redfree, cobalt blue
  13. Illumination Bulb: 12V/30W halogen bulb
  14. Voltage/Frequency: AC220V ± 10%/60HZ ±1HZ, AC110V ± 10%/50HZ ± 1HZ
  15. Power: 58VA
  16. Electrical safety standard: Conform to Standard IEC 601-1, Class1 Type B
  17. Whole Packaging Volume: 0.30M3
  18. Carton Number: 2
  19. Total Weight: 51KGS

Accessories:

  • Applanation Tonometer (R type and T type)
  • Measuring Eyepiece
Weight2400 g
Dimensions72 × 49.5 × 48 cm
