Features:

  1. By the way of double locating, it would correct errors automatically.
  2. Offering more clearer and sharper pictures.
  3. Increase the picture density; there are 5 icons in one line.
  4. The charts are bigger, size: 33*22.5(CM) (in 5M refraction).
  5. Projected by wireless remote controller.
  6. Able to project charts one by one.
  7. Standard accessories, the metal board is covered by bias material.

Specifications:

  1. Projection distance: 2-6M
  2. Projection magnification: 30x (in 5M refraction)
  3. Numbers of charts: 33
  4. Chart change-over: 3 frame/sec
  5. Numbers of masks: 1 open, 3 horizontal line, 8 vertical line, 16 single isolation, 1 red and green
  6. Tilt range: 10° horizontally as well as vertically
  7. Bulb: high-luminance and long-life LED light source
  8. Image shift interval: 0.5 second
  9. Automatic shut-off mechanism: 5 minutes
  10. Input voltage: AC 110V/60HZ or 220V/50HZ
  11. Power consumption: 65W
  12. Dimensions: 19.6(W)*29.2(L)*23.4(H)(CM)
  13. Weight: 6.5KGS
Weight6500 g
Dimensions29.2 × 19.6 × 23.4 cm
